5100018329

Wacker Neuson WP1540AW Plate With Water Kit (Honda Engine)

Out of stock
£1,674.00 £1,395.00

Important: 3-week delivery lead time

Complete your purchase with...
  • This Item:
    £1,674.00 £1,395.00
  • Wacker Neuson Water Kit for WP1540A Compaction Plate
    £300.00 £250.00

Product Information

Professionals prefer the WP series high-performance vibratory plates for their superior compaction capabilities, making them the go-to choice for asphalt, interlocking paving stones, and compacting mixed soils in restricted areas. Their resilient and long-lasting design positions them as the optimal tools for ongoing professional utilisation in road construction. Specifically tailored for compacting sandy and granular sub bases in locations such as sidewalks, roads, and parking lots, these plates excel in various applications. Operator safety is prioritised with low pollutant emissions, enhancing overall working conditions. Furthermore, the WP series vibratory plates offer flexibility in positioning on construction sites, easily movable to desired locations through the optional wheel set.



  • Low-Maintenance Advantage: Designed for a low Total Cost of Ownership (TCO), the equipment features a low-maintenance design, ensuring cost-effectiveness over its operational life.
  • Sturdy Protective Framework: A robust protective frame surrounds the engine and water tank, providing durability and safeguarding vital components from potential damage during operation.
  • Optimised Base Plate Shape: The base plate is meticulously shaped for optimal performance, enhancing compaction efficiency and delivering superior results on various surfaces.
  • Efficient Fuel Management and Four-Stroke Operation: The engine integrates a carburetor for efficient fuel management and operates in a reliable four-stroke mode, ensuring controlled power delivery.
  • Enhanced User Safety and Comfort: Operator safety is prioritized with low pollutant emissions, fostering improved working conditions for enhanced comfort and protection during operation.
  • Flexibility with Optional Wheel Set: The WP series vibratory plates offer flexibility in positioning on construction sites, providing easy mobility to desired locations through the optional wheel set.

Specification

More Information
SKU:5100018329
Barcode5061043461529
Plate DirectionSingle Direction
BrandWacker Neuson
ModelWP1540AW
Weight92.000000
Width430 mm
Height961 mm
Centrifugal Force15,000 kN
Area Capacity749 m2/h
Forward Running29,00 m/min
Gradeability36,4 %
Vibrations (Hz)98,0 Hz
Width Baseplate430 mm
Operating Weight92kg
Ground Clearance525 mm
Effective Power3,1 kW, 3,6 kW
Normal Engine Speed3.600 1/min, 3.600 1/min
HAV Summation (Average Value)5,3 m/s2
HAV Summation (Standard)EN 500-4
